PFT101 fiber positioning system
1. Provides two dimensional tilt adjustment
2. With a dovetail mount , can be used for fix the mount of optical parts
3. It can be combined with TMS202M to compose five axis adjusting rack
4. Hands paired design
- description
- parameters
|
Model |
PFT101 |
|
|
Adjustment range（mm） |
θy |
±5° |
|
θz |
±5° |
|
|
Center height of optical path（mm） |
79 |
|
|
Resolution（mm） |
5″ |
|
|
Weight（kg） |
0.3 |
|
