TMS200 series multi-axis positioning stages
1.Actuated
with linear ball guides, allowing for stable movement and high precision.
2.Driven withmicrometer head.
3.The
motion can be easily locked withthe knobon the side of the stage.
4.Separate
models are available for right-hand and left-hand use.
- description
- parameters
|
Model |
TMS201M |
TMS202M |
|
Axles |
XY two axles |
XYZ three axles |
|
Travel （mm） |
25 |
|
|
Driving |
micrometer head |
|
|
Graduation（mm） |
0.01 |
|
|
Resolution（mm） |
0.002 |
|
|
Error of swing |
＜30″ |
|
|
Loading capacity (kg) |
6 |
2.5 |
|
Weight （kg） |
0.7 |
1.1 |
