WDG30-Z monochromator

    1. Triple exchangeable grating turret

    2. USB2.0 interface

    3. Windows operating platform

    4. Full wave-band automatic scan

  • description
  • parameters

WDG30-Z monochromator


1. Triple exchangeable grating turret

2. USB2.0 interface

3. Windows operating platform

4. Full wave-band automatic scan


Model

WDG30-Z

Focal Length (mm)

300

Relative Aperture

f/4

Mechanical Scanning Range (nm)

200~1500

Resolution (nm)

0.1 nm

Reciprocal Dispersion (nm/mm)

2.7 nm/ mm

Wavelength Accuracy (nm)

0.2nm

Wavelength Repeatability (nm)

0.1

Step size(nm)

0.005

Slit

Width: 0.1-3mm, optional motorized slit .
Height: Optional10mm

Focal Plane area (mm)

25×10

Grating turret

Triple

Size (mm)

360×260×195

Weight (kg)

15
