WDG15-Z monochromator
1, Small size ,easy to move
2. Double exchangeable grating turret
3. USB2.0 interface
4. Windows operating platform
5. Full wave-band automatic scan
- description
- parameters
|
Model |
WDG15-Z |
|
Focal Length (mm) |
150 |
|
Relative Aperture |
f/4 |
|
Mechanical Scanning Range (nm) |
200~1500 |
|
Resolution (nm) |
0.4 nm |
|
Reciprocal Dispersion (nm/mm) |
5.4 nm/ mm |
|
Wavelength Accuracy (nm) |
0.25nm |
|
Wavelength Repeatability (nm) |
0.1 |
|
Step size(nm) |
0.01 |
|
Slit |
Width:
0.11-3mm, optional motorized slit . |
|
Focal Plane area (mm) |
25×10 |
|
Grating turret |
Dual |
|
Size (mm) |
190×200×160 |
|
Weight (kg) |
5 |
