HB400 series automatic balanced flotation optical tables

    1. Used high quality stainless steel in table top ,Core is Steel honeycomb, air cushion vibration isolation, can be automatic balance

    2. Planeness less than 0.05mm/m2, surface roughness 0.8 to 1.6μm

    3. Natural frequency 1.2Hz to 2.0Hz

  • description
  • parameters

HB400 series automatic balanced flotation optical tables




1. Used high quality stainless steel in table top ,Core is Steel honeycomb, air cushion vibration isolation, can be automatic balance

2. Planeness less than 0.05mm/m2, surface roughness 0.8 to 1.6μm

3. Natural frequency 1.2Hz to 2.0Hz



Model

Table sizemm

Comment

Weightkg

HB401

1800×1200×800

air cushion ,4 supportsM6 screw hole array distance 25max load 800 KG

400

HB402

2000×1000×800

air cushion ,4 supportsM6 screw hole array distance 25max load 800 KG

450

HB403

2000×1200×800

air cushion ,4 supportsM6 screw hole array distance 25max load 800 KG

520

HB404

2400×1200×800

air cushion ,4 supportsM6 screw hole array distance 25max load 800 KG

650

HB405

3000×1000×800

air cushion ,6 supportsM6 screw hole array distance 50max load 950 KG

900

HB406

3000×1200×800

air cushion ,6 supportsM6 screw hole array distance 50max load 950 KG

1150

HB407

3000×1500×800

air cushion ,6 supportsM6 screw hole array distance 50max load 950 KG

1250

HB408

3500×1200×800

air cushion ,6 supportsM6 screw hole array distance 50max load 950 KG

1350

HB409

3500×1500×800

air cushion ,6 supportsM6 screw hole array distance 50max load 1200 KG

1750

HB410

4000×1500×800

air cushion ,6 supportsM6 screw hole array distance 50max load 1200 KG

1850

HB411

4200×1500×800

air cushion ,6 supportsM6 screw hole array distance 125max load 1500 KG

2000

HB412

4800×1500×800

air cushion ,8 supportsM6 screw hole array distance 125max load 2500 KG

2300

HB413

5400×1500×800

air cushion ,8 supportsM6 screw hole array distance 125max load 2500 KG

2600

HB414

6000×1500×800

air cushion ,8 supportsM6 screw hole array distance 125max load 2500 KG

2900
