GM200 series mirror mounts
1. Two axis rotation orthogonal coplanar
2. Coarse adjustment and fine adjustment.
3. M6×0.25 fine thread screw adjustment
4. Pressing lens by a thread screwing rotation
5. Locking by hand wheel
- description
- parameters
|
Model |
GM201 |
GM202 |
GM202B |
GM204 |
|
|
Applied diameter ΦA |
40 |
50 |
50.8 |
64 |
|
|
ΦB |
34 |
46 |
46 |
60 |
|
|
Adjustment range |
Coarse adjustment |
360° |
|||
|
Fine adjustment |
±3° |
||||
|
C |
26 |
26 |
26 |
32 |
|
|
D |
103 |
119 |
119 |
149 |
|
|
E |
72 |
82 |
82 |
101 |
|
|
F |
112 |
132 |
132 |
166 |
|
|
Weight（kg） |
0.55 |
0.65 |
0.65 |
0.75 |
|
