SLM100 series self-centering lens mounts
1. Three pivots of the coaxial lens mounts continuously open simultaneously, automatic reset by spring
2. When the replacement of lens, center of lens will be not changed
- description
- parameters
|
Model |
SLM101 |
SLM102 |
SLM103 |
|
|
Applied diameter ΦA |
MIN |
5 |
5 |
5 |
|
MAX |
50 |
76 |
102 |
|
|
ΦB |
46 |
72 |
100 |
|
|
C |
70 |
102 |
140 |
|
|
D |
90 |
126 |
160 |
|
|
E |
11 |
16 |
16 |
|
|
F |
19 |
30 |
30 |
|
|
Weight（kg） |
0.10 |
0.20 |
0.35 |
|
