BS201 beam steeper

    1. Can applied prism

    2. Driving by M6×0.25 fine thread screw

    3. High quality dished spring reset

    4. Used 12mm diameter support post to fix

    5. Tilt adjustment by double axis

  • description
  • parameters

BS201 beam steeper




1. Can applied prism

2. Driving by M6×0.25 fine thread screw

3. High quality dished spring reset

4. Used 12mm diameter support post to fix

5. Tilt adjustment by double axis



Model

BS201

Lifting height for beammm

180

Applied diameter

25×25

Adjusting range of tilt

θx

±4°

θy

±4°

Rotation angle of mirror mounts

θz

360°

Weightkg

0.8
